YJLV22-0.6/1kV

Product Name: Aluminum core XLPE insulated steel tape armored PVC sheathed power cable

Executive Standard: GB/T 12706.1-2008

Product Features:

1. The rated power frequency voltage U0/U (Um) is 0.6/1 (1.2) kV;

2. The maximum allowable working temperature of the cable conductor is 90℃;

3. When short-circuit (the longest duration does not exceed 5s), the maximum temperature of the cable conductor does not exceed 250°C.

Application: It is suitable for the distribution of electric energy in low-voltage power frequency distribution lines. It can be laid indoors, outdoors, cable trenches, and bridges, and can withstand a certain external mechanical pressure.
